| Model Number |
VIP-HNC328MB-2.8 |
|
| Image Sensor |
1/2.5″ progressive scan CMOS |
|
| Min. illumination |
0.01 lux @ (F1.2, AGC ON), 0 lux with IR |
|
| Shutter time |
1/3s ~ 1/100,000s |
|
| Lens |
2.8mm @ F2.0 Angle of view: 63.5° / Optional 4.0mm |
|
| Day & night |
IR cut filter with auto switch |
|
| Digital noise reduction |
3D DNR |
|
| Wide dynamic range |
True WDR |
|
| Video compression |
H.265 /H.264+/H.264/ MJPEG |
|
| Max. Image Resolution |
3840×2160 |
|
| Frame rate |
15fps (3840×2160), 30fps (2560×1920) |
|
| Image settings |
Saturation, brightness, contrast, sharpness adjustable through client software or web browser |
|
| storage |
NAS, on board 128GB SD card slot |
|
| Alarm trigger |
motion detection, tampering alarm, network disconnect, IP address conflict, storage exception |
|
| Protocols |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos |
|
| Security |
User Authentication, reset button, flickerless, dual stream, heartbeat, mirror, watermark |
|
| Communication interface |
1 RJ45 10M/ 100 M Ethernet interface |
|
| Operating conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) humidity 90% or less (non-condensing) |
|
| Power supply |
12 VDC +/- 10%, PoE (802.3af) |
|
| Power consumption |
Max, 7W |
|
| Weather proof rating |
IP67 |
|
| IR range |
UP to 100ft |
|
| Dimension |
Φ2.76″ × 6.1″ |
|
| Weight |
0.9lbs |
|
| Electrical Box |
HTH-280ZJ-XS |
|
