| Model Number |
VIP-HNC326TD-2.8 |
|
| Image Sensor |
1/2.9″ progressive scan CMOS |
|
| Min. illumination |
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
|
| Shutter time |
1/3s ~ 1/100,000s |
|
| Lens |
4mm @ F1.2, angle of view: 63.5° (2.8, 6mm optional) |
|
| Angle adjustment |
Pan:0° ~ 355°, tilt 0° ~ 75°, Rotation: 0°~ 355° |
|
| Digital noise reduction |
3D DNR |
|
| Wide dynamic range |
True WDR |
|
| Day & night |
ICR |
|
| Video compression |
H.264 / H.264+ / H.265 / H.265+ / MJPEG |
|
| Dual stream |
Yes |
|
| Max. image resolution |
3072×2048 |
|
| Frame rate |
20fps(3072×2048), 30fps(2560×1440) |
|
| Image settings |
Saturation, brightness, contrast, sharpness adjustable through client software or web browser |
|
| BLC |
Yes, zone configurable |
|
| On Board Storage |
Micro SD slot, up to 128GB |
|
| Alarm trigger |
Motion detection, tampering alarm |
|
| Protocols |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos |
|
| System compatibility |
ONVIF(PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
|
| General functionalities |
One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter |
|
| Communication interface |
1 RJ45 10M / 100M self-adaptive Ethernet interface |
|
| Operating conditions |
-30°C ~ 60°C (-22°F ~ 140°F) humidity 95% or less (non-condensing) |
|
| Power supply |
12 VDC +/- 25%, PoE (802.3af) |
|
| Power consumption |
12 VDC, 6.2W; PoE(802.3af, class 3), 9 W |
|
| Ratings |
IP67 / IK10 |
|
| IR range |
Up to 100ft |
|
| Dimensions |
Ø 4.4″x3.2″ |
|
| Weight |
500g (1.1 lbs) |
|
| Electrical Box |
HTH-280ZJ-DM18 |
|
| Wall Mount |
HTH-258ZJ, HTH-272ZJ-110B |
|
| Pendant |
HTH-271ZJ-110 |
|
| Corner and Pole |
C:HTH-276ZJ, P:HTH-275ZJ |
|
