Details
| Max Image Resolution |
4MP |
| Image Sensor |
1/3” 3Megapixel progresive CMOS |
| Image Size |
2688(H)x1520(V) |
| RAM/ROM |
512MB/32MB |
| Electronic Shutter |
Auto/Manual, 1/3(4)~1/100000s |
| Minimum Illumination |
- 0.08Lux/F2.0( Color,1/3s,30IRE)
- 0.3Lux/F2.0( Color,1/30s,30IRE)
- 0Lux/F2.0(IR on)
|
| S/N Ratio |
More than 45dB |
| IR LEDs |
24 |
| Smart IR |
Support |
| IR Distance |
Distance up to 30m(98ft) |
| IR On/Off Control |
Auto/ Manual |
| Focal Length |
2.8mm |
| Angle of View |
H:104°/87°, V:57°/48° |
| Max. Aperture |
F2.0/F2.0 |
| Optical Zoom |
N/A |
| Close Focus Distance |
N/A |
| DORI Distance |
| Lens |
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
63(207ft)
|
25(82ft)
|
13(43ft)
|
6(20ft)
|
|
| Pan / Tilt / Rotation |
Pan:0° ~355° ;Tilt:0° ~64° ;Rotation:0° ~355° |
| IVS |
N/A |
| Advanced Intelligent Functions |
N/A |
| Video Compression |
H.265+/H.265/H.264+/H.264 |
| Streaming Capability |
2 Streams |
| Video Resolution |
4M(2688x1520/2560x1440)/3M(2304×1296)/ 1080P(1920×1080)/720P(1280×720)/ D1(704×576/704×480)/ CIF(352×288/352×240)
|
| Video Frame Rate |
- 4M(1 ~ 20fps)/3M (1 ~ 25/30fps)
- D1/CIF(1 ~ 25/30fps)
|
| Video Bitrate |
- H.265: 12K ~ 8448Kbps
- H.264: 32K ~ 10240Kbps
|
| Day / Night |
Auto(ICR) / Color / B/W |
| BLC Mode |
BLC / HLC / WDR(120dB) |
| White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control |
Auto/Manual |
| Digital Noise Reduction |
3D DNR |
| Motion Detection |
Off / On (4 Zone, Rectangle) |
| Region of Interest |
Off / On (4 Zone) |
| Electronic Image Stabilization (EIS) |
Support |
| Defog |
N/A |
| Digital Zoom |
16x |
| Flip |
0°/90°/180°/270° |
| Mirror |
Off / On |
| Privacy Masking |
Off / On (4 Area, Rectangle) |
| Audio Compression |
N/A |
| IPC Alarm |
N/A |
| Ethernet |
RJ-45 (10/100Base-T) |
| Network Protocol |
HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP |
| Network Interoperability |
ONVIF, PSIA, CGI |
| Streaming Method |
Unicast / Multicast |
| Network Max. Users |
20 Users |
| Storage |
NAS Local PC for instant recording |
| Storage Card |
N/A |
| Web Viewer |
IE, Chrome, Firefox, Safari |
| Management Software |
Smart PSS, DSS,Easy4ip |
| Mobile |
iPhone, Android |
| Video Output |
N/A |
| Certifications |
CE (EN 60950:2000), UL:UL60950-1, FCC: FCC Part 15 Subpart B |
| Audio Interface |
N/A |
| RS485 |
N/A |
| Alarm In |
N/A |
| Alarm Out |
N/A |
| Power Supply |
DC12V PoE(802.3af)(Class 0) |
| Power Consumption |
<4.58W |
| Operating Temperature |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
| Storage Temperature |
-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH |
| Ingress Protection |
IP67 |
| Dimensions |
109.9mm × 81mm (4.33" x 3.19") |
| Weight |
0.47Kg (1.04lb) |
Additional Information
| UPC |
No |
| Camera Housing |
Bullet |
| Camera Resolution |
1.3MP / 720P |
| Camera Technology |
IP |
IP Dome: 4MP Network IP LXIR Bullet Camera, 3.6mm Fixed Lens, IR(263ft), IP67, PoE
