| Video & Audio Input |
| Analog Video Input |
4ch(1.0Vp-p, 75 Ω) |
| HDTVI Input |
5MP Lite, 1080P, 720P |
| CVI Input |
4MP, 1080P, 720P |
| AHD Input |
5MP Lite, 1080P, 720P |
| CVBS Input |
Support |
| IP video Input |
2CH 1080p in default mode
Up to 5MP in full IP mode(6CH) |
| Audio Input |
1-ch, RCA(2.0 Vp-p, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input) |
| Video & Audio Output |
| HDMI |
1ch, resolution: 2K(2560*1440/60Hz), 1920×1080/60Hz,1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| VGA |
1ch, resolution: 1920×1080/60Hz,1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| CVBS/ Spot Output |
1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
| Audio Output |
1-ch, RCA(Linear, 1kΩ) |
| Recording |
| Video Compression |
H.265+/H.265 H.264+/H.264 |
| Encoding Resolution |
5MP lite/1080P/1080P Lite/720P/960H/D1 |
| Frame Rate(fps) |
Main stream: 4CH 5MP Lite/1080p 12fps; 1080p/720P/960H/D1/CIF Real Time |
| Video Bit Rate |
11Kbps~ 10240Kbps |
| Audio Compression |
G.711a |
| Audio Bit Rate |
64kbps |
| Playback & Backup |
| Playback Number |
4ch Playback |
| Playback Mode |
Smart Playback/Normal/Time Division/ Label/ Event/ Picture playback |
| Backup Mode |
USB Device/Network |
| Advanced Features |
| Smart Detection for Analog |
4CH Line Crossing Detection, Intrusion Detection |
| Smart Detection for IPC (Original Manufacturer) |
Line Crossing Detection, Area Intrusion detection, Face Detection |
| Smart Playback for Analog |
Motion detection,line crossing detection,intrusion detection |
| Smart Playback for IPC (Original Manufacturer) |
Face Detection, Motion Detection,Line Crossing Detection, Intrusion Detection |
| Cloud Storage |
Support |
| Cloud Upgrade |
Support |
| Network Management |
| Network interface |
1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface |
| Network Function |
HTTPs, HTTP,TCP/IP,IPv4,UPnP,Onvif 2.6,RTSP,RTCP,UDP, SMTP,SNMP,Multicast,IGMP,NTP, DHCP,DNS,DDNS, FTP, |
| Mobile Apps |
UVMMS for iPhone®, iPad® and Android™ |
| Cloud-P2P (URL) |
www.uvmms.net |
| Hard Disk |
| Interface Type |
1 SATA Interface |
| Capacity |
Up to 10TB capacity for each HDD |
| External Interface |
| Serial Interface |
Standard RS-485 Half Duplex |
| USB Interface |
Front panel: 1 × USB 2.0,Rear panel: 1 × USB 2.0 |
| General |
| Power Supply |
DC12V,2A |
| Power Consumption |
≤10W(without HDD) |
| Working Environment |
-10°C~+55°C / 10%~90%RH |
| Dimension (W×D×H) |
315 x 240 x 45mm |
| Weight(without HDD) |
2.1kg |
