| Video & Audio Input |
| Analog Video Input |
8ch(1.0Vp-p, 75 Ω) |
| HDTVI Input |
8MP, 5MP,3MP,1080P, 720P |
| CVI Input |
4MP,1080P, 720P |
| AHD Input |
5MP,4MP,1080P, 720P |
| CVBS Input |
Support |
| IP video Input |
8ch,up to 8MP resolution up to 16ch in full IP mode |
| Audio Input |
4-ch, RCA(2.0 Vp-p, 1 KΩ) |
| Two-Way Audio |
1-ch, multiplex with Audio Input(RCA) |
| Video & Audio Output |
| HDMI |
1ch, resolution: 4K(3840×2160)/30Hz,1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz |
| VGA |
1ch, resolution: 1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz |
| CVBS/ Spot Output |
1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
| Audio Output |
1-ch, RCA(Linear, 1kΩ) |
| Recording |
| Video Compression |
H.265+/H.265 H.264+/H.264 |
| Encoding Resolution |
8MP/5MP/4MP/3MP/1080P/1080P Lite/720P/960H/D1 |
| Resolution |
Main stream: 8CH 8MP@7fps, 5MP@12fps,4MP@15fps
1080P/720P/960H/D1@25fps(P)/30fps(N) |
| Frame Rate(fps) |
1-25fps |
| Video Bit Rate |
11Kbps~ 10Mbps |
| Record Mode |
Manual, Schedule,Alarm |
| Audio Compression |
G.711a |
| Audio Bit Rate |
64kbps |
| Playback & Backup |
| Playback Number |
8CH Playback |
| Playback Mode |
Smart Playback/Normal/Time Division/ Label/ Event/ Picture playback |
| Backup Mode |
USB Device/Network |
| Advanced Features |
| Smart Detection for Analog |
8CH Line Crossing Detection, Intrusion Detection |
| Smart Detection for IPC (Original Manufacturer) |
Line Crossing Detection, Area Intrusion Detection, Region Entrance, Region Exiting, Fast moving, Unattached Object, Object Missing, Face Detection |
| Smart Playback for Analog |
Line Crossing/Are Intrution/Motion Detection |
| Smart Playback for IPC (Original Manufacturer) |
Face Detection/Line Crossing/Are Intrution/Motion Detection |
| Cloud Storage |
Support |
| Cloud Upgrade |
Support |
| Network |
| Ethernet |
1 RJ-45 10 /100/1000 Mbps self-adaptive Ethernet interface |
| Network Function |
HTTPs, HTTP,TCP/IP,IPv4,UPnP,Onvif 2.6,RTSP,RTCP,UDP, SMTP,SNMP,Multicast,IGMP,NTP, DHCP,DNS,DDNS, FTP, P2P |
| Mobile Apps |
UVMMS for iPhone®, iPad® and Android™ |
| Cloud-P2P (URL) |
www.uvmms.net |
| Hard Disk |
| SATA |
1 SATA interfaces |
| Capacity |
Up to 10TB capacity for each HDD |
| External Interface |
| Serial Interface |
Standard RS-485(half-duplex) |
| USB Interface |
Front panel: 1 × USB 2.0, Rear panel: 1 × USB 2.0 |
| Alarm Input |
8ch |
| Alarm Output |
4ch |
| General |
| Power Supply |
DC12V,5A |
| Power Consumption |
≤20W(without HDD) |
| Working Environment |
-10°C~+55°C / 10%~90%RH |
| Dimension (W×D×H) |
315 x 240 x 45mm |
| Weight(without HDD) |
2.1kg |
