| Max Image Resolution |
MP |
| System Compression |
H.265/ H.264 |
| Main Processor |
Embedded Processor |
| Video Out |
1 HDMI, 1 VGA |
| Video Resolution |
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
| IPC In |
32CH |
| Display Split |
1/4/8/9/16/25/36 |
| Audio In |
1 |
| Audio Out |
1 |
| 2 Way Audio |
1 Channel Input, 1 Channel Output, RCA |
| Recording Resolution |
8MP, 6MP, 5MP, 3MP, 1080P, 1.3MP, 720P, etc |
| Recording Rate |
200Mbps |
| Bit Rate |
16~20Mbps |
| Recording Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop |
| Record Interval |
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Alarm In |
16 Channel |
| Alarm Out |
4 Channel |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering |
| Alarm Relay Output |
4 Channel |
| Playback Channels |
1/4/9/16 |
| Playback Search |
Time/Calendar Search, Event (motion) |
| Playback Function |
Play, Pause, FF, FB; Digital zoom |
| Backup Mode |
USB Device, network |
| Network Interface |
1 RJ-45 Port(10/100/1000Mbps) |
| PoE Ports |
16 ports (IEEE802.3af/at) |
| Network Function |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip |
| Network Max. Users |
128 users |
| Mobile |
iPhone, Android |
| USB |
2 ports(1 USB2.0, 1 USB3.0) |
| RS485 |
1 port, for PTZ control |
| RS232 |
1 port, for communication with PC or keyboard |
| Internal HDD |
4 SATA III Ports, Up to 6 TB capacity for each HDD |
| e-SATA |
N/A |
| Power Supply |
AC100V ~ 240V, 50 ~ 60 Hz |
| Power Consumption |
NVR: <13.7W (Without HDD) PoE: Max 25.5w for single port, 150w in total |
| Operating Conditions |
-10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimensions |
1.5U, 440mm×411.1mm×76mm (17.3" x 16.2" x 3.0") |
| Weight |
Net Weight 4.5kg (9.9 lb) (without HDD) Gross Weight 7kg(15.4 lb)(without HDD) |
