| Max Image Resolution |
4MP |
| System Compression |
H.265+/H.265/H.264+/H.264 |
| Main Processor |
Embedded Processor |
| Video Interface |
1 HDMI, 1 VGA |
| Video Resolution |
1920x1080, 1280x1024, 1280x720 |
| Multi-Screen Display |
When IP extension mode not enabled: 1/4; When IP extension mode enabled: 1/4/6 |
| HDCVI Camera Input | 4MP/1080P@25/30fps, 720P@50/60fps, 720P@25/30fps |
| IPC In |
4+2 Channel, each channel up to 6MP |
| OSD |
Yes |
| Audio In |
1 |
| Audio Out |
1 |
| 2 Way Audio |
Reuse audio in/out, RCA |
| Recording Resolution | 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF |
| Recording Frame Rate |
Mainstream: 5M-N1~10fps), 4M-N/1080P(1~15fps); 1080P/720P/960H/D1/CIF(1~25/30fps)
Substream: D1/CIF (1~15fps)
|
| Bit Rate |
32Kbps ~ 6144Kbps Per Channel |
| Recording Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), alarm, stop |
| Record Interval |
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Playback Channels |
1/4 |
| Playback Search |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device/Network |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 x 18), Video Loss, Tampering and Diagnosis |
| Alarm In |
N/A |
| Alarm Relay Output |
N/A |
| Network Interface |
1 RJ-45 Port (100M) |
| Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
| Network Max. Users |
128 |
| Interoperability |
ONVIF 16.12, CGI Conformant |
| Mobile |
iPhone, Android |
| RS485 |
1 Port, for PTZ Control |
| USB |
2 USB Ports (1 USB 2.0, 1 USB 3.0) |
| RS232 |
N/A |
| RS422 |
N/A |
| Power Supply |
DC12V/4A |
| Power Consumption |
<10W (Without HDD) |
| Internal HDD |
1 SATA Port, up to 10TB capacity |
| e-SATA |
N/A |
| Operating Conditions |
-10°C ~ +55°C (+14°F ~ 131°F), 10%~90% RH |
| Storage Conditions |
-20°C ~ +70°C (-4°F ~ 158°F), 0~90% RH |
| Dimensions |
Mini 1U, 325mm×255mm×55mm (12.8" x 10" x 2.2") |
| Weight |
Net weight 1.0kg (2.2lb) (without HDD); Gross weight 1.9kg (4.2lb) |
