Details
| Max Image Resolution | 5MP |
|---|---|
| System Compression | H.265 High profile |
| Main Processor | Embedded Processor |
| Video Compatibility | HD-TVI / AHD / CVI |
| Max. Video Channels | 32CH |
| Video In | BNC x 32 |
| IPC In | 8CH |
| IPC Resolution | 5MP/4MP/3MP/1080P/720P/WD1 |
| IPC Frame Rate | 25fps ( PAL ) / 30fps ( NTSC ) |
| Video Interface | HDMI/VGA/CVBS |
| Video Resolution | HDMI × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 |
| Multi-Screen Display | N/A |
| OSD | No |
| Audio In | 16CH, RCA |
| Audio Out | 1CH, RCA |
| 2 Way Audio | Take up channel one as an audio input |
| Recording Resolution | 5MP Lite/4MP Lite/1080P/1080P Lite/720P/WD1 |
| Recording Frame Rate | 5MP Lite@10fps 4MP Lite/1080P@12fps/15fps (PAL / NTSC) 1080P Lite/720P/WD1@25fps/30fps (PAL / NTSC) |
| Recording Encode | N/A |
| Recording Quality | N/A |
| Recording Mode | Manual, Timer, Motion |
| Recording File Management | N/A |
| Playback Channels | 16CH |
| Playback Search | Time slice / time / event / tag search |
| Playback Smart Search | Highlight colors to display the camera record in a certain period of time, different colors refer to different record events |
| Playback Function | Play, pause, FF, FB, digital zoom, etc. |
| Alarm In | 16 CH |
| Alarm Out | 4 CH |
| Alarm Mode | Manual, motion, exception |
| Trigger Events | Record,snap,alarm out,e-mail, etc |
| Network Bandwidth | 88/160Mbps |
| Network Function | TCP/IP、PPPoE、DHCP、DNS、DDNS、UPnP、NTP、SMTP |
| Network Max. Users | N/A |
| Mobile | iPhone, Android |
| Cellphone Function | N/A |
| RS485 | RS485 × 1, connect to PTZ or keyboard |
| USB | 2 x USB 2.0 |
| remote | Optional |
| Power Supply | ATX 250W |
| Power Consumption | ＜30W (without HDD) |
| Internal HDD | 4 x SATA (up to 8TB capacity for each disk) |
| e-SATA | e-SATA x 1 |
| Operating Conditions | -10~50°C, 10%~90% (Humidity) |
| Dimensions | 440mm x 390mm x 70mm (W x D x H) |
Additional Information
| UPC | No |
|---|---|
| Recorder Technology | Penta-brid: HDCVI / HDTVI / AHD / Analog / IP |
| Recorder Channel | 32 Channel |
| Recording Rate | 5MP |
